520mm Inline Printing Machine , 3 Color Opp Film Flexo Printing Machine

Brand Name : ruiting

Model Number : RYIN520-3

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 25 sets/month

Delivery Time : in 30 days after receiving the deposit

Packaging Details : Wooden Case

Usage : horizontal flexo printer

Dimensions(l*w*h) : 2900*1200*1200mm

Voltage : 380V,3phase,50HZ

Warranty : 1 Year

Name : 3 Color 520mm Opp Film Horizontal Flexo Printer With UV

Printing Color : 3 color

Application : film, aluminium foil

Max. material width : 520mm

Printing speed : 10-150m/min

Weight : 2200KGS

Contact Now

3 Color 520mm Opp Film Horizontal Flexo Printer With Touch Screen Operate

Main features

  • Unwind: Use auto loading system, Vector motor tension control system
  • Ceramic anilox cylinder to transfer the ink
  • Auto stop function when lacking material
  • Adopt ultrasonic web guide system
  • Printing unit: 360°Plate-adjustment
  • IR dryer for each printing unit
  • Auto clean printing plate system: when off the anilox roller, plate cylinder will tranfer ink on material, keep the printing plate clean.
  • 3 inch air shaft both unwinding and rewinding
  • Touch screen display
  • Frequency converter for speed controlling
  • 3 plate cylinders and 3 ceramic anilox rollers

Main technical specification:

Model RTIN-520-3
Printing speed 150m/minute
Printing color number 3 color
Max width of paper 520mm
Max printing wide 520mm
Max unwinding diameter 600mm
Max rewinding diameter 600mm
Printing length 175-635mm
Precision of overprint ±0.1mm
Overall dimension 2.9(L)×1.2(W)×1.2(H)m
Weight about 2200kg

Optional parts:(can add as your request)

  • Printing unit number, up to 10 colors;
  • turn bar device;
  • Slitting set
  • Video monitor
  • Rotary die cutting set
  • Cold laminating

Material details:

Printing material paper,foil, PVC,
Printing ink UV ink,water based ink
Printing plate thcikness 1.7mm
