paper die cut letters flatbed die cutting for self adhesive label
Product Description
This die cutting machine is flat bedstructure, computer-servo system pull material.
The maximum speed can reach 300m/min, and functions such as slitting, cross-cutting, and hot stamping can be added. Feeding-die cutting-waste discharge-rewinding sheet cutting, all processes are completed by computer in one time.It is a good machine for efficient production.
Main features
A:Unwinding+closed loop tension control
B:Web Guider
C.Closed-loop tension control
D:Servo motors+Trio motion controller
E:Die cutting with slitter
F:HMI Touch screen operating system(Schneider+PLC)
Main Technical Specification:
| Model | 330 model | | cut speed | 300 time/min | | Max unwinding diameter | 330mm | | Max web width | 330mm | | Max die-cut Length | 50-310mm | | Position accuracy | ±0.1mm | | Total power | 11kw | | Power voltage | 380V, 3 phase (can make as your request) | | Machine weight | About3000kg | | Overall dimension | 2.6(L)×1.2(W)×1.5(H)(m) | | | |
Material details:
| material | paper label, foam tape, PVC label |
| cutting mould | steel |
FQA
1.Are you factory or trading company?
We are factory.
2.What is your after service?
We offer customer a lifetime service.
3.Do you have CE certificate?
Yes, we have CE certificate of our machines.
4.What is the shipping time?
Around 15-30 days, depend on different model.
5.What can I do if machine stop work?
You can email us, call us or online video calls, face to face solve problem.
If the spare parts or something broken, in the warranty time,
we offer free.
